This handbook of tables has been compiled to help the crane operator and estimator determine boom and jib combinations quickly and accurately. It should be used with a lifting capacity chart.

"Maximum Reach" is defined as the greatest horizontal distance that can be reached across a structure by a crane equipped with a boom of known length."

The first objective of this handbook was to solve a large number of combinations involving structures of known heights and booms of known lengths for the "maximum reach, " then tabulate them for quick reference.

Secondly, it was desired to solve the same combinations for just "reach" by varying the operating radius. "Reach" is the horizontal distance across a structure when the rig is positioned so that "maximum reach" does not occur. This was done by using various values for the distance from the structure to the center pin.
